Product Description
-
- Rotor kits are exclusively developed for upgrading from OE iron rotors with a 100% direct bolt on installation.
- Discs are made of long carbon fibers and are directional, so they are stronger and can run cooler than
Brembo's chopped carbon fibers and straight vanes. - Rotors will fit under OE calipers w/o requiring any caliper or dust shiled modification like other aftermarket kits made with Corvette ZR1 discs.
- Rotors (front & rear) are made with larger annulus to accomondate deeper pads (same as ZR1) that can help to run the brake cooler than OE size pads. Also compatible with stock size pads.
- Rear rotor hats are made with iron sleeve insert and is 100% compatible with OE emergency brakes.
- 2 ea front CCM rotors (390x34mm) - No caliper modification is required
- 2 ea rear CCM rotors (380x30mm) - No dust shield trimming is required
- 1 set CCB RB ST600 brake pads (ZR1 size - Deeper than GTR OE pads)
ROTOR WT. COMPARISON (LBS) | FRONT | REAR | TOTAL |
OE | 28.6 | 27 | 55.6 |
RB | 14.56 | 13.16 | 27.72 |
Saving/Side | 14.04 | 13.84 | 27.88 |
Saving/Car | 55.76 |
Replacement brake pads:
(ZR1 size pads are deeper than OE (13mm on front, 7mm on rear)
**Pagid/Endless pads are subject to availability.
Replacement rotor rings:
Rotor pricing references:
Compared to Surface Transforms:
